Package includes
- STRIKER Vivid 5cv
- GT20-TM transducer
- Power/data cable
- Tilt/swivel mount
- Hardware
- Documentation
A new way to see what’s under the water.
CLEAR, COLOURFUL SONAR
Choose from 7 new vivid colour options to see fish and structure in maximum contrast and clarity on your 5″ fishfinder.
BUILT-IN SONAR
Use the included GT20 transducer to get Garmin CHIRP traditional sonar and CHIRP ClearVü scanning sonar.
WAYPOINT MARKING
To catch more fish, you need to know where the fish are biting. Use waypoint marking for hot spots so you can easily find your way back.
HIGH-SENSITIVITY GPS
Plan and create routes and view your boat’s speed on your fishfinder using high-sensitivity GPS.
QUICKDRAW CONTOURS
Nobody knows the waters you fish better than you. With the STRIKER Vivid 5cv fishfinder, you can store up to 2 million acres of maps with 1’ contours1.
INCLUDED HARDWARE
The STRIKER Vivid 5cv fishfinder includes a tilt/swivel mount plus transom and trolling motor mounting hardware and cable.
Physical & Performance
Display resolution 800 x 480 pixels
Physical dimensions 7.4’’ x 4.5’’ x 2.1’’ (18.8 x 11.6 x 5.4 cm)
Water rating IPX7
Weight 1.0 lb (0.5 kg)
Display type WVGA colour
Features
Fish Symbol ID (helps identify fish targets) Yes
Transmit power 500 W (RMS)
Water temperature log and graph Yes
Audible alarms Yes
AutoGain Technology (minimises clutter, maximises targets) Yes
Dual-beam (77/200 kHz) sonar capable Yes
Additional
One 4-pin transducer port
Quickdraw Contours
Integrated GPS
Mark Waypoints
Course over Ground (COG)
Current draw @ 12V: 0.40A
Water temperature sensor included Yes
Split-screen zoom Yes
A-scope (real time display of fish passing through transducer beam) Yes
Adjustable depth line (measures depth of underwater objects) Yes
Dual-frequency (50/200 kHz) sonar capable Yes
Bottom lock (shows return from the bottom up) Yes
Frequencies supported Traditional: 50/77/200 kHz CHIRP (mid and high) ClearVü: 260/455/800 kHz
Ultrascroll® (displays fish targets at higher boat speeds) Yes
